Engine Type: 4 Cylinders
Bore x Strock: 102 mm * 120 mm
Displacement: 3.9 L
Rated Power: 24 kW to 96 kW
Emission Standard: N/A
DCEC Generator Drive Engine
DCEC CMS’s reliable and durable G-Drive diesel engine providing global G-OEMs with a cost-effective and fully integrated G-Drive product.
DCEC generator drive engines covering displacement from 3.9 to 13 liters, with power range from 22kW to 500kW.
To avoid mismatching problems and guarantee the outstanding performance of DCEC G-drive engines, all of DCEC G-drives engines are comes with complete power pack, which provide the engine, radiator and air filter as Coolpac for customer. Each parts of Coolpac have been designed and validated according to the CMS standard. Ensure the customers can easy and quick to design and produce Gen-set with capable and reliable Coolpac components.
Integrated designed cooling radiator system greatly reduced the complexity of installation. The optimized cover of rotation unit at front of engine can prevent accidental injury effectively. Our product had passed strict vibration, thermal cycling and corrosion test, Dongfeng CMS-DCEC G-drive engines can be used in all kinds of harsh environment like tropical, frigid zone, high altitude and high corrosion area.
Multiple configuration can be provided to fit different performance level of Gen-set. The mechanical governor advantage is safety, stability and low-cost, it can meet G1 level; The electronic governor and ECM advantage provide accurate speed control, it can meet G2 & G3 and even higher requirement.
Advantages of G-Drive Engine
Dongfeng CMS-DCEC optimized the installation air filter system according to the engine structure, which reduced the outline dimension of Coolpac. Two filter to make sure that the filtration efficiency can reach 99.5%, it can avoid abnormal abrasion of the engine. Also we can provide the special type air filter system which can fit extreme applications, such as high altitude, dust or humidity.
Whether you need standby or emergency, continuous or prime power, you can rest assured there’s a DCEC CMS G-Drive product to fit your application.
Find G-drive Engines by Type
This is the list of all types of DCEC G-drive engines.
Click here to find G-drive engines by series.
1500 RPM Mechanical G-Drive Engine
6BT5.9 M-Governor
Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 86 kW to 145 kW
Emission Standard: N/A
6CTA8.3 M-Governor
Engine Type: 6 Cylinders
Displacement: 8.3 L
Bore x Strock: 114 mm * 135 mm
Rated Power: 163 kW to 183 kW
Emission Standard: N/A
6CTA8.3 E-Governor
Engine Type: 6 Cylinders
Displacement: 8.3 L
Bore x Strock: 114 mm * 135 mm
Rated Power: 163 kW to 183 kW
Emission Standard: N/A
6LTAA8.9 E-Governor
Engine Type: 6 Cylinders
Displacement: 8.9 L
Bore x Strock: 114 mm * 145 mm
Rated Power: 220 kW to 230 kW
Emission Standard: N/A
6LTAA9.5 E-Governor
Engine Type: 6 Cylinders
Displacement: 9.5 L
Bore x Strock: 116.5 mm * 148 mm
Rated Power: 250 kW to 290 kW
Emission Standard: N/A
6ZTAA13 E-Governor
Engine Type: 6 Cylinders
Displacement: 13.0 L
Bore x Strock: 130 mm * 163 mm
Rated Power: 455 kW to 537 kW
Emission Standard: N/A
1500 RPM Electronic G-Drive Engine
QSB3.9 E-Governor
Engine Type: 4 Cylinders
Displacement: 3.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 63 kW to 79 kW
Emission Standard: N/A
QSB4.5 E-Governor
Engine Type: 4 Cylinders
Displacement: 4.5 L
Bore x Strock: 107 mm * 124 mm
Rated Power: 206 kW
Emission Standard: N/A
QSB5.9 E-Governor
Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 96 kW to 120 kW
Emission Standard: N/A
QSB6.7 E-Governor
Engine Type: 6 Cylinders
Displacement: 6.7 L
Bore x Strock: 107 mm * 124 mm
Rated Power: 151 kW to 168 kW
Emission Standard: N/A
QSL8.9 E-Governor
Engine Type: 6 Cylinders
Displacement: 8.9 L
Bore x Strock: 114 mm * 144.5 mm
Rated Power: 206 kW to 235 kW
Emission Standard: N/A
QSZ13 E-Governor
Engine Type: 6 Cylinders
Displacement: 13.0 L
Bore x Strock: 130 mm * 163 mm
Rated Power: 482 kW to 603kW
Emission Standard: N/A
1800 RPM Mechanical G-Drive Engine
4BT3.9 M-Governor
Engine Type: 4 Cylinders
Bore x Strock: 102 mm * 120 mm
Displacement: 3.9 L
Rated Power: 24 kW to 96 kW
Emission Standard: N/A
6BT5.9 E-Governor
Engine Type: 6 Cylinders
Displacement: 5.9 L
Bore x Strock: 102 mm * 120 mm
Rated Power: 86 kW to 145 kW
Emission Standard: N/A
6CTA8.3 E-Governor
Engine Type: 6 Cylinders
Displacement: 8.3 L
Bore x Strock: 114 mm * 135 mm
Rated Power: 163 kW to 183 kW
Emission Standard: N/A
6LTAA8.9 E-Governor
Engine Type: 6 Cylinders
Displacement: 8.9 L
Bore x Strock: 114 mm * 145 mm
Rated Power: 220 kW to 230 kW
Emission Standard: N/A
6LTAA9.5 E-Governor
Engine Type: 6 Cylinders
Displacement: 9.5 L
Bore x Strock: 116.5 mm * 148 mm
Rated Power: 250 kW to 290 kW
Emission Standard: N/A
6ZTAA13 E-Governor
Engine Type: 6 Cylinders
Displacement: 13.0 L
Bore x Strock: 130 mm * 163 mm
Rated Power: 455 kW to 537 kW
Emission Standard: N/A
1800 RPM Electronic G-Drive Engine
QSM11 E-Governor
Engine Type: 6 Cylinders
Displacement: 10.8 L
Bore x Strock: 125 mm * 147 mm
Rated Power: 319 kW
Emission Standard: N/A
QSZ13 E-Governor
Engine Type: 6 Cylinders
Displacement: 13.0 L
Bore x Strock: 130 mm * 163 mm
Rated Power: 482 kW to 603kW
Emission Standard: N/A
